Heltec 48V 60V BMS 16S 60A 80A 120A 160A 200A 250A 300A 350A Lifepo4/lipo battery protection board solar energy storage
$28.00
16S 60A 3.2V Same Port SKU:0955 Size: 115×66×10 Overcharge protection : 3.75v Over-discharge protection : 2.1v Abnormal high voltage protection Temperature protection optional Maximum continuous current : 60A Discharge over current protection : 250A Load short circuit protection Balance current : 67 m Charging recovery Application Applicable to all kinds...
16S 60A 3.2V Same Port
SKU:0955
Size: 115×66×10
Overcharge protection : 3.75v
Over-discharge protection : 2.1v
Abnormal high voltage protection
Temperature protection optional
Maximum continuous current : 60A
Discharge over current protection : 250A
Load short circuit protection
Balance current : 67 m
Charging recovery
Application
Applicable to all kinds of common customized high and medium power lithium batteries
16S 80A 3.2V Same Port
SKU:1926
Charging protection voltage: 3.75V
Discharge protection voltage: 2.2V
Charge release voltage: 3.55V
Discharge release voltage: 2.70V
Balance voltage 3.50V
Balance current: 73MA
Max continuous overcurrent value: 80A
Instantaneous current limit value: 415A
Short circuit protection: load short circuit
Dimensions: 115×66×8MM
Weight: 75g
Main application range: electric vehicles within 48V1200W, 48V marine propellers, 48V lawn mowers and other electrical products
16S 80A 3.7V Same Port
SKU:1926
Charging protection voltage: 4.25V
Discharge protection voltage: 2.7V
Charge release voltage: 4.15V
Discharge release voltage: 3.0V
Balanced voltage 4.18V
Balance current: 83MA
Max Continuous overcurrent value: 80A
Instantaneous current limit value: 415A
Short circuit protection: load short circuit
Dimensions: 115×66×8MM
Weight: 75g
Main application range: electric vehicles within 60V1200W, 48V marine propellers, 48V lawn mowers and other electrical products
16S 120A 3.2V Same Port
SKU:0967
Size: 115×66×17
Internal resistance:4mΩ
Overcharge protection : 3.75v
Over-discharge protection : 2.1v
Abnormal high voltage protection
Temperature protection optional
Maximum continuous current : 120A
Discharge over current protection : 500A
Load short circuit protection
Balance current : 67 mA
Charging recovery
Application:Applicable to all kinds of common customized high and medium power lithium batteries
16S 120A 3.7V Same Port
SKU:0957
Size: 115×66×17
Overcharge protection : 4.28v
Over-discharge protection : 2.7v
Abnormal high voltage protection
Temperature protection optional
Maximum continuous current : 120A
Discharge over current protection : 500A
Load short circuit protection
Balance current : : 83 mA
Charging recovery
Application:
Applicable to all kinds of common customized high and medium power lithium batteries
16S 160A 3.2V Same Port
SKU:1335
Size: 115 * 66 * 14MM
Charge protection voltage: 3.75V
Charge release voltage 3.6V
Discharge protection voltage 2.1V
Discharge release voltage 2.5V
Balanced voltage 3.55V
Balanced current: 83MA
Maximum continuous overcurrent 160A
Instantaneous current limit protection: 550A
Short circuit protection: load short circuit protection
16S 160A 3.7V Same Port
SKU:1334
Charging protection voltage: 4.25V
Discharge protection voltage: 2.7V
Charge release voltage: 4.15V
Discharge release voltage: 3.0V
Balanced voltage 4.18V
Balance current: 83MA
Max continuous overcurrent value: 160A
Instantaneous current limit value: 750A
Short circuit protection: load short circuit
Dimensions: 115×66×14MM
Weight: 100g
Main applications: electric vehicles within 60V2500W, 48V marine propellers, 48V lawn mowers and other electrical products
16S 200A 3.2V Same Port
Charging protection voltage: 3.75V
Discharge protection voltage: 2.2V
Charge release voltage: 3.55V
Discharge release voltage: 2.70V
Balance voltage 3.50V
Balance current: 73MA
Max Continuous overcurrent value: 200A
Instantaneous current limit value: 900A
Short circuit protection: load short circuit
Dimensions: 190×97×14MM
Weight: 220g
Main application range: four-wheel electric vehicles within 48V5000W, high-power marine propellers, and other electric products
16S 200A 3.7V Same Port
Charging protection voltage: 4.25V
Discharge protection voltage: 2.7V
Charge release voltage: 4.15V
Discharge release voltage: 3.0V
Balanced voltage 4.18V
Balance current: 83MA
Max ontinuous overcurrent value: 200A
Instantaneous current limit value: 900A
Short circuit protection: load short circuit
Dimensions: 190×97×14MM
Weight: 220g
Main application range: four-wheel electric vehicles within 48V4000W, high-power marine propellers, and other electric products
16S 250A 3.2V Same Port
SKU:1468
Charging protection voltage: 3.75V
Discharge protection voltage: 2.2V
Charge release voltage: 3.55V
Discharge release voltage: 2.70V
Balance voltage 3.50V
Balance current: 73MA
Max Continuous overcurrent value: 250A
Instantaneous current limit value: 1 100A
Short circuit protection: load short circuit
Dimensions: 150×80×14MM
Weight: 220g
Main application range: four-wheel electric vehicles within
48V5000W, high-power marine propellers, and other electric products
16S 250A 3.7V Same Port
SKU:1467
Charging protection voltage: 4.25V
Discharge protection voltage: 2.7V
Charge release voltage: 4.15V
Discharge release voltage: 3.0V
Balanced voltage 4.18V
Balance current: 83MA
Max continuous overcurrent value: 250A
Instantaneous current limit value: 1100A
Short circuit protection: load short circuit
Dimensions: 150×80×14MM
Weight: 220g
Main application range: four-wheel electric vehicles within 60V5000W, high-power marine propulsion, and other electric products
16S 300A 3.2V Same Port
Charging protection voltage: 3.75V
Discharge protection voltage: 2.2V
Charge release voltage: 3.55V
Discharge release voltage: 2.70V
Balance voltage 3.50V
Balance current: 73MA
Max Continuous overcurrent value: 300A
Instantaneous current limit value: 1500A
Short circuit protection: load short circuit
Dimensions: 190×97×14MM
Weight: 220g
Main application range: four-wheel electric vehicles within 48V7000W, high-power marine propellers, and other electric products
16S 300A 3.7V Same Port
Charging protection voltage: 4.25V
Discharge protection voltage: 2.7V
Charge release voltage: 4.15V
Discharge release voltage: 3.0V
Balanced voltage 4.18V
Balance current: 83MA
Max continuous overcurrent value: 300A
Instantaneous current limit value: 1500A
Short circuit protection: load short circuit
Dimensions: 190×97×14MM
Weight: 220g
Main application range: four-wheel electric vehicles within 60V7000W, high-power marine propellers, and other electric products
16S 150A 3.2V Split Port
Charging protection voltage: 3.75V
Discharge protection voltage: 2.2V
Charge release voltage: 3.55V
Discharge release voltage: 2.70V
Balance voltage 3.50V
Balance current: 73MA
Charging current: 60A
Maximum continuous overcurrent for a long time: 150A
Instantaneous current limit value: 600A
Short circuit protection: load short circuit
Dimensions: 150×80×14MM
Weight: 200g
Suitable for: household 48V high-power solar energy storage, matching solar panels within 2000W, continuous load equipment within 5000W
16S 250A 3.2V Split Port
SKU：1620
Charging protection voltage: 3.75V
Discharge protection voltage: 2.2V
Charge release voltage: 3.55V
Discharge release voltage: 2.70V
Balance voltage 3.50V
Balance current: 73MA
Long-term charging current: 100A
Maximum continuous overcurrent for a long time: 250A
Instantaneous current limit value: 1100A
Short circuit protection: load short circuit
Dimensions: 150×80×14MM
Weight: 220g
Suitable for: household 48V high-power solar energy storage, matching solar panels within 3800W, load instant power matching within 9000W, continuous load equipment within 5000W
16S 350A 3.2V Split Port
SKU：2103
Charging protection voltage: 3.75V
Discharge protection voltage: 2.2V
Charge release voltage: 3.55V
Discharge release voltage: 2.70V
Balance voltage 3.50V
Balance current: 73MA
Long-term charging current: 200A
Maximum continuous overcurrent for a long time: 350A
Instantaneous current limit value: 1500A
Short circuit protection: load short circuit
Dimensions: 209×97×14MM
Weight: 300g
Suitable for: household 48V high-power solar energy storage, matching solar panels within 6000W, load instant power matching load equipment within 10KW
16S 130A 3.7V Same Port
This BMS if you need you can contact us , this one internal resistance is less
SKU:0957A
Size: 115×66×17
Internal resistance:1.8mΩ
Overcharge protection : 4.28v
Over-discharge protection : 2.7v
Abnormal high voltage protection
Temperature protection optional
Maximum continuous current : 120A
Discharge over current protection : 500A
Load short circuit protection
Balance current : : 83 mA
Charging recovery
Application:
Applicable to all kinds of common customized high and medium power lithium batteries
