Products
8S Lifepo4 BMS 8S 120A 18650 BMS Balance Board for 3.2V LifePO4 Battery protection board 29V 25.6V
$41.58
8S 120A 3.2V Same Port Size: 115×66×17Overcharge protection : 3.75vOvercharge release voltage: 3.6VBalanced turn-on voltage: 3.55VDischarge protection voltage: 2.1VOver-discharge release voltage: 2.5VAbnormal high voltage protectionTemperature protection optionalMaximum continuous current:120ADischarge over current protection : 250A/500A/500A/1000ALoad short...
9S 10S 11S 12S 13S 14S 5A Active Equalizer Balancer Lifepo4 Lithium Lipo LTO Battery Energy active equalization Capacitor Group
$52.99
Measured fault battery pack combination 4 string 25Ah equalization curve As the battery battery cycle times increase, the battery capacity decay speed is inconsistent, causing the battery voltage to be seriously out of balance. The...
Active Equalizer balancer vs bms Bluetooth Smart BMS 13S 14S 15S 16S 17S -20S 60A 120A RS485 APP Lifepo4 li-ion 48V 52V 60V
$68.00
Feature String(Lifepo4)：13-17SString(Li-ion) ：13-17SOutlet method：Same PortCell voltage：1-5VVoltage acquisition accuracy：±5mVContinuous discharge current：60ADischarge current(MAX)：120AEquilibrium method：Active BalanceEquilibrium current：0.6AMain circuit conduction internal resistance：1.3mΩOvercharge protection voltage：2.5-4.25V adjustableOvercharge release voltage：2.5-4.25V adjustableCharging overcurrent protection (adjustable)：10-60ACharging overcurrent release time：2-120S adjustableOver discharge protection voltage：2.5-4.25V adjustableOver...
BMS 8S 80A BMS 29V 25.6V 18650 Balance Board for 3.2V LifePO4 Battery protection board
$36.65
8S 80A 3.2V Same Port Size: 115×66×17MMOvercharge protection : 3.75vOvercharge release voltage: 3.6VBalanced turn-on voltage: 3.55VDischarge protection voltage: 2.1VOver-discharge release voltage: 2.5VAbnormal high voltage protectionTemperature protection optionalMaximum continuous current : 2:80ADischarge over current protection :500ALoad...
BMS 10S 15A Balance Board 36V 3.7V li-ion lipo battery protection board
$19.50
10S15A 3.7V Same Port
Size: 63×48×8MMOvercharge protection : 4.28vOver-discharge protection : 2.8vAbnormal high voltage protectionTemperature protection optionalMaximum continuous current : 15ADischarge over current protection : 100ALoad short circuit protectionBalance current : 83 mACharging recovery
BMS 12S 60A Balance 3.7V 18650 Li-ion Battery protection board 3 Choice with difference size and performace for choice
$18.99
12S 60A 3.7V Same Port TyPe A Size: 115×66×10 mmTyPe B Size: 115×66×10 mm Better material, low internal resistance, less heatType C Size: 72*55*14mmOvercharge protection : 4.28vOver-discharge protection : 2.7vAbnormal high voltage protectionTemperature protection optionalMaximum...
BMS 12S 60A Balance 3.7V 18650 Li-ion Battery protection board customized high medium power lithium batteries
$27.59
12S 60A 3.7V Same Port 240A 360A If needed , pls contact us freely. Size: 115×66×10 Overcharge protection : 4.28v Over-discharge protection : 2.7v Abnormal high voltage protection Temperature protection optional Maximum continuous current :...
BMS 12S 60A Split Port Balance 3.7v lipo battery protection Board for 36V 24V 48V Electric bicycle electric tools within 1200W
$18.89
10S 12S 13S 14S 60A 3.7V Split Port Size:78×60×17mm Overcharge protection : 4.28v Over-discharge protection : 2.9v Abnormal high voltage protection Temperature protection optional Maximum continuous current : 60A Discharge over current protection :...
BMS 12S16S 160A Balance Board for 3.7V 18650 Li-ion /Lipo /3.2V Lifepo4 Battery protection board Balance
$51.00
Can be connected with weak point switch to control output 12S 16S 160A 3.7V Same Port Size: 115*66*14mm Overcharge protection : 4.28v Over-discharge protection : 2.7v Abnormal high voltage protection Temperature protection optional Maximum continuous...
BMS 3S 4S Balance 100A 120A 160A 200A 300A 380 12.6V/16.8V 18650 Battery Protection Board Li-ion/LiFePo4 Ups inverter/motorcycle
$8.49
3S 4S 100A 3.7V Split Port Applicable assembly:3.7V Ternary lithium battery, 18650 battery, etc Serial port: 3s 4s/ split port Size: 83×55×8 Overcharge protection voltage: 4.28V Over-discharge protection voltage: 2.5V Abnormal high voltage protection: yes...
BMS 3S 4S Balance 120A 12.6V/16.8V 18650 Battery Protection Board Li-ion/LiFePo4 Ups inverter, motorcycle, car
$12.89
3S 4S 120A 3.7V Applicable assembly:3.7V Ternary lithium battery, 18650 battery, etc Serial port: 3s 4s/ Same port Size: 77×55×14 Overcharge protection voltage: 4.28V Over-discharge protection voltage: 2.9V Abnormal high voltage protection: yes Temperature...
BMS 3S 4S Balance 200A 12.6V/16.8V 18650 Battery Protection Board Li-ion/Lipo Suitable for load battery less than 2000W
$39.89
3S 4S 200A 3.7V Applicable assembly:3.7V Ternary lithium battery, 18650 battery, etc Serial port: 3s 4s/ Same port Size: 115×66×18 Overcharge protection voltage: 4.28V Over-discharge protection voltage: 2.5V Abnormal high...
